ORFS male x METRIC male 1.5mm pitch 90° positional forged elbow

Products > O Ring Face Seal Adaptors > ORFS male x METRIC male 1.5mm pitch 90° positional forged elbow

ORFS male x METRIC male 1.5mm pitch 90° positional forged elbow

Products
Technical Info
Data Sheet

ORFS male x METRIC male 1.5mm pitch 90° positional forged elbow
ORFS male x METRIC male 1.5mm pitch 90° positional forged elbow Drawing
9515-04-M109/16 Orfs x M10 by 1mm Male x Male 90° Positional Elbow£5.54
9515-04-M129/16 Orfs x M12 Male x Male 90° Positional Elbow£5.66
9515-04-M149/16 Orfs x M14 Male x Male 90° Positional Elbow£5.99
9515-04-M169/16 Orfs x M16 Male x Male 90° Positional Elbow£5.99
9515-04-M189/16 Orfs x M18 Male x Male 90° Positional Elbow£6.36
9515-06-M1611/16 Orfs x M16 Male x Male 90° Positional Elbow£6.32
9515-06-M1811/16 Orfs x M18 Male x Male 90° Positional Elbow£6.36
9515-06-M2011/16 Orfs x M20 Male x Male 90° Positional ElbowSuperseded UseNLA
9515-06-M2211/16 Orfs x M22 Male x Male 90° Positional ElbowSuperseded UseNLA
9515-08-M1213/16 Orfs x M12 Male x Male 90° Positional ElbowSuperseded UseNLA
9515-08-M1413/16 Orfs x M14 Male x Male 90° Positional Elbow£6.29
9515-08-M1613/16 Orfs x M16 Male x Male 90° Positional Elbow£6.33
9515-08-M1813/16 Orfs x M18 Male x Male 90° Positional Elbow£6.36
9515-08-M2013/16 Orfs x M20 Male x Male 90° Positional Elbow£7.23
9515-08-M2213/16 Orfs x M22 Male x Male 90° Positional Elbow£7.64
9515-10-M161 Orfs x M16 Male x Male 90° Positional Elbow£6.44
9515-10-M181 Orfs x M18 Male x Male 90° Positional Elbow£8.09
9515-10-M201 Orfs x M20 Male x Male 90° Positional Elbow£8.03
9515-10-M221 Orfs x M22 Male x Male 90° Positional Elbow£8.87
9515-12-M161-3/16 orfs x M16 Male x Male 90° Positional Elbow£10.98
9515-12-M181-3/16 Orfs x M18 Male x Male 90° Positional Elbow£11.12
9515-12-M201-3/16 Orfs x M20 Male x Male 90° Positional ElbowSuperseded UseNLA
9515-12-M221-3/16 Orfs x M22 Male x Male 90° Positional Elbow£11.25
9515-12-M241-3/16 Orfs x M24 Male x Male 90° Positional Elbow£11.73
9515-12-M261-3/16 Orfs x M26 Male x Male 90° Positional Elbow£11.73 Out Of Stock
